The PICT- NI LabVIEW Academy, established in 2013, is a state of the art facility which aims at providing certified training under the guidance of NI expertise and PICT NI Certified Faculty to the Faculty from Engineering Colleges, Research Scholars, Engineering students on LabVIEW and hands-on exposure to industry standard tools.

The LabVIEW Academy program provides academic institutions with a classroom curriculum package that supports both credit noncredit courses. It gives student access to industry standard tools they can use in classes, labs and beyond. PICT has been honored with “LabVIEW Academy School qualification certificate”, during NIDAYS 2016 – Annual Graphical System Design Conference. We gained access to LabVIEW Core-1 and Core-2 curriculum result for industry classes and LabVIEW academy program. We use NI recommended syllabuses and complimentary hardware to develop the courses quickly. The lab is equipped with the state of the art facilities such as

Universal Software defined Radio Peripherals (NI USRP- 2922) with Tri-band 7 inch vertical Antenna.(Frequency Range: 400MHz-4.4 GHz)

NI My DAQ (2 channel Analog Input, One digital Input output 8 pin port, Audio Input Output Connectivity)

LabVIEW Professional Development System Software

The main objective of the laboratory is to conduct training programs and carry out academic and industrial research in the field of data acquisition, wireless communications, and embedded systems. UG, PG, PhD students are encouraged to take up projects, research in these areas. Faculty explores carrying out continuous research and attract industry project, consultancy projects and funded projects from various funding agencies.

Software Defined Radio Facilities:

Major Equipments:

Sr.No	Laboratory Equipment	Specification	Quantity	Cost in Rs
1	Universal Software defined Radio Peripherals	Frequency Range: 400MHz-4.4 GHz	06	13,57,282/-
2	NI My DAQ	2 channel Analog Input One digital Input output 8 pin port Audio Input Output connectivity	10	60,000/-

Software:

Sr.No	EDA Tool	Specification	Quantity	Cost in Rs
1	LabVIEW – Professional Development System	Rich set of functions and controls Drivers for USRP and MyDAQ	20	3,66,190/-

Microwave and antenna Facilities:

---

Major Equipments

Sr.No	Laboratory Equipment	Specification	Quantity	Cost in Rs
1	Antenna Training Lab 5 MHz – 2 GHz, Model ATS – 20	Transmitter Receiver with mechanical assembly Stepper motor controller with mech. Assembly Coaxial slotted line Directional Coupler Antenna Types : a) Yagi Uda b) Microstrip c) Parabolic Dish d) Helix e) Array Antenna f) Loop Antenna and related antennas.	1	287213/-
2	Amitech Antenna training lab 5MHz2GHz without Antennas- Transmitter and receiver Tripod, Plotting Software., Model – ATS20 Base – A	Operating Frequency: 5MHz to 2GHz. Transmitter Receiver with mechanical assembly Stepper motor controller with mech. Assembly	1	133593.75/-
3	AMITech Antenna training lab with TFT touch Screen display with 16 Antennas, Model – ATS04 and Directional Coupler Base – A	Operating Frequency: 5MHz to 4GHz. Inbuilt Transmitter and Receiver with mechanical assembly Stepper motor controller with mech. Assembly	1	454000/-
4	Magnetron	Magnetron Mount with Flange (2-3 Mhz, VSWR = 1, Power CCW: 1000 watt LG2M214	1	54875/-
5	Waveguide to N-Type Adapter	Waveguide to N-Type Adapter (2-3 Mhz, VSWR = 1, Power CCW: 1000 watt LG2M214	1	31857/-
6	Microstrip Trainer Kit	1.C-band source Model No.SSS-980C	1	262991/-
		2. Detector Model No MD-985C	2
		3. Power supply Model no-PS-990C	1
		4. Coupler-Model No MC-995C	1
		5. Universal Testing Jig Model No UTZ-970	3
		6. Stand	6
7	Microwave Test Bench	Reflex Klystron based microwave test bench	4	263002/-
8	Microwave Test Bench	Gunn based microwave test bench	2	127734/-
9	Doppler RADAR Trainer Kit	AMITEC make Doppler Radar Training System10 GH Model DXR10	1	106875/-
		1. Radar with stand & Dish	1
		2. Microwave absorber	1
		3. Radar Jammer	1
		4. Target Emulator	2
		5. Tunning fork	1
		6. Rotating Blades (Fan)	1
		7. Speed regulator	1
		8. Piezo Buzzer	1
		9. Pendulum	1
		10. Power supply	4
		11. CD for DXR10-	1
10	VNA(Vector Network Analyzer	ZVL13 Network Analyzer 9KHz to 13.6 GHz ( S.N. – 102157 )	1	109620/-
		ZV-Z192 HF cable N(M) – PC 3.5 mm (m)( S.N.-101455, 101456)	2	56700/-
		ZV-Z135 Calibration Kit 3.5 MM ( S.N.-102458)	1	56700/-

Software:

Sr.No	EDA Tool	Specification	Quantity	Cost in Rs
1	ANSYS 18 Software ( 5 Users )	ANSYS Academic Teaching HF Packages	1	340000/-
2	AWR Software (40 Users)	MWO -449 – UV Microwave office university Inclusive of APLAC and AXIEM	1	341250/-
3	CADFEKO 5.5 Software	A CAD tool for passive wave guide components & antennas ( 5 Users ) Software	1	400000/-

Sr. No.	Name of the faculty / student (Inventors)	Title	Application no.	Date of filing (Filed / Published / Granted)	Status: Applied / Published/ Granted / Licensed
Nil	Nil	Nil	Nil	Nil

Check following link:

• Paper Publications

Sr.No	Name of the Faculty	Certification	Academic Year
1	Mr. Zakee Ahmed	Certified LabVIEW Associate Developer	2015-16
2	Mr. Nilesh Shirude	Certified LabVIEW Associate Developer	2017-18
3	Mr. Akshay Pawar	Certified LabVIEW Associate Developer	2017-18

Check following link:

• Conducted Workshops, Faculty Training Programs, Certification Programs, STTPs

Inauguration of PICT- NI LabVIEW Academy : Exchanging M.O.U.

From Left to right: Dr. P. T. Kulkarni, Shri. Swastik Sirsikar, Shri. R.S. Kothavale, Mr. Manish Dhruv and Dr. Y. Ravinder

PICT- NI LabVIEW Academy Lab: Demonstration of project work
From Left to right: Dr. S. S. Narkhede, Dr. Y. Ravinder, Mr. Manish Dhruv, Dr. P. T. Kulkarni, Shri. Swastik Sirsikar, Shri. R.S. Kothavale and final year students

(College has been honored with “LabVIEW Academy School qualification certificate”, during NIDAYS 2016)

(Prof. P. S. Varade demonstrating NI USRP LabVIEW Programming”, 13th – 14th September 2014)

(Inauguration of one week online AICTE Sponsored Short Term training program on “Energy efficient techniques for 5g wireless communications”)

(Inauguration of National Level workshop on “Software Defined Radio with LabVIEW and NI USRP”)

(Prof. Zakee Ahmed conducting LabVIEW session at MIT, Aurangabad)

(Participants attending session in A Three Days AICTE Funded National Level Workshop on “Cognitive Radio Techniques for 5G Wireless Communications”)

(One week IETE sponsored STTP on ―LabVIEW: Modern Tools and Techniques in Engineering Education was conducted at MIT Aurangabad)

(Dr. Shabbir Merchant conducting session on “Software Defined Radio”)

(A Three Days AICTE Funded National Level Workshop on “Cognitive Radio Techniques for 5G Wireless Communication”)

Please fill following Google Form:

• Google Form Link
